QT10-15 Automatic Concrete Block Making Machine
|
Our QT10-15 machine combines proven technology with user-friendly operation, making it the ideal choice for new and expanding block production facilities worldwide. With its robust design and efficient production capabilities, you'll achieve consistent quality and maximum output with minimal operational complexity.
|
 |
 |
Specification
|
Overall Dimension
|
5600×2400×2950(mm)
|
|
Rated pressure
|
25MPa
|
|
Main vibration form
|
Platform vibration
|
|
Motor Frequency
|
50/60HZ
|
|
Exciting force
|
100KN
|
|
Cycle Time
|
15-25 seconds
|
|
Vibrating Frequency
|
2800-4500 rolls/minute
|
|
Overall weight
|
13500kg
|
|
Motors Power
|
49.5KW
|
|
Pallet Size
|
1200*900(mm)
|
|
Raw Materials
|
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes
|
|
Key Features & Benefits:
|
| Size(LxWxH) | Reference Picture | Cycle Molding | Pcs/Mould | Pcs/Hour | Pcs/10hrs | |
| 400x200x200mm |  |
10-15s | 10 | 2400-3000 | 24000-30000 | |
| 400x100x200mm | |
10-15s | 20 | 4800-6000 | 48000-60000 | |
| 400x150x200mm | |
10-15s | 14 | 3360-4200 | 33600-42000 | |
| 240x115x53 |  |
10-15s | 51 | 12240-15300 | 122400-153000 | |
| 245x130x60 |  |
10-15s | 24 | 5760-7200 | 57600-72000 | |
Use Scenarios
Factory Owners Managing Daily High-Volume Block Production
Large and medium block factories rely on predictable, continuous production to meet customer timelines. QT10-15 provides stable daily output while maintaining block uniformity across multiple shifts. As an Automatic Concrete Block Making Machine, it supports long-run production with reduced manual involvement, ensuring consistent quality across every batch.
Construction Engineers Supplying Materials for Public and Commercial Projects
Engineers tasked with infrastructure or commercial development require blocks with reliable load performance and dimensional accuracy. QT10-15 produces high-strength bricks, curbstones, and pavers that meet project durability requirements. The concrete blocks machine enables engineers to maintain consistent material flows throughout the project timeline.
Contractors Establishing On-Site or Regional Block Production Facilities
For contractors managing large residential or commercial developments, the QT10-15 helps reduce transportation and procurement delays by enabling near-site or regional block production. Acting as an efficient brick maker, it supports diverse block types needed across different construction phases while lowering logistical costs and improving project scheduling flexibility.
FAQ
1.What types of blocks can QT10-15 produce?
It supports hollow blocks, solid bricks, pavers, curbstones, and various interlocking designs.
2.What materials work best with the machine?
Standard concrete mixtures using sand, aggregates, cement, fly ash, and recycled materials.
3.Does it support long-term continuous production?
Yes. Its vibration system and structural components are engineered for sustained high-duty operation.
4.Is mold replacement easy?
Yes. The quick-change system allows rapid switching between mold types.
5.Can DFSL provide setup and operator training?
Yes. We offer installation guidance, technical support, and operator training sessions.
